Rock Road

Rock Road Luminaires are designed to be mounted in Outdoor, Industrial Areas, moisture zones, Parking lots, Tunnels as well as warehouse, Factories, Utility areas and Sub stations. Special design of Rock Road enables the End Users to apply this product as a multi-application for both Indoor and Outdoor areas. High efficiency, Powerful and homogenic Illumination , with a quality and professional selection of fine Electrical components are just a few remarkable features of Rock Road.

Certificates

IP65

IK08

Housing

Made of Die Cast Aluminum with excellent resistant against heavy Mechanical and Heat Shocks.

Coating by automatic powder coating system RAL 7015.

Frame made Die Cast Aluminum

Cover

Made of Heat and Shock resistant Glass

Sealants made of special silicon gasket with premium

durability to ensure IP maintenance in life time zone

Electrical components

Fine quality Constant current LED Driver, Flicker Free, – PF>0.9

Internal wiring made of Flameproof covered copper wires

Screwless Terminal Block made of Polycarbonate

Fine Quality SMD-LED module, nominate life time 100.000 hours at L70 with excellent efficiency

Color Temperature CCT 4000 K (6000 K as an Option by Order)

LED lenses made of fine quality Polyamide

 Nominated Voltage and Frequency

220-240 V. AC

50-60 HZ

Entries

Two M20 Cable Entry at one end of external Junction Box

Mounting

Rock Road Luminaire are easily applied as Wall mounted,

Pendant, Pole/Bracket mounted and Tower mounted

Options (by Order)

Through Wiring, Looping Wiring

Extra M20 or M25 Entry

Brass made Nickel Plate Cable Gland

Selection of different mounting accessories suitable for Wall Mounting, Surface or Pendant mounting, Cable Tray, Lighting Pole and Bracket, Chain-Rod
