VICTOR
Victor Luminaires are designed to be mounted in Hazardous Areas, Zone 1 , 21 , Zone 2 , 22 specially Outdoor, Petrochemical and Refinery Areas..
Technical design of Victor enables the Oil, Gas and Petrochemical Plants to apply this product in Potentially Explosive environment, Utility areas as well as Walkways. High efficiency, Smooth and homogenic light Distribution, Glare control, with a quality and professional selection of fine Electrical components are just a few remarkable features of Victor series.
Certificates
IP66/67
EEx d
IK08
Housing
Made of Die Cast Aluminum with excellent resistant against heavy Mechanical and Heat Shocks.
Coating by automatic powder coating system RAL 7015
End Caps made of powder coated Die Cast Aluminum
Cover
Made of Borosilicate tempered Glass
Diffuser made of Polycarbonate (for LED version)
Sealants made of special glues, silicone gaskets with premium durability to
ensure IP and EEx maintenance in life time zone
Electrical components
Fine quality Constant current LED Driver, Flicker Free, – PF>0.9
Internal wiring made of PVC covered copper wires
Screwless Terminal Block made of
Polycarbonate
Fine Quality SMD-LED module, nominate life time 100.000 hours at L70 with excellent efficiency
Color Temperature CCT 4000 K (6000 K as an Option by Order)
Nominated Voltage and Frequency
220-240 V. AC
50-60 HZ
Entries
One M25 Cable Entry at one End equipped with one EEx M25 Brass made Nickel plated Cable Gland
Mounting
Victor Luminaire are easily applied as Surface mounted, Pendant, Wall Mounted and Pol/
Bracket mounted
Options (by Order)
Through Wiring, Looping Wiring
Extra M25 Entry
Brass made Nickel Plate Cable Gland or Blind Plug
DALI protocol LED Driver
Emergency Back Up Battery with 90 min. or 180 min. autonomy
Selection of different mounting accessories suitable for Wall Mounting, Surface or
Pendant mounting, Cable Tray, Lighting Pole and Bracket, Chain-Rod
| Reference | Power (Watt) | Luminaire Luminous Flux (lm) | Efficiency
(lm/W) |
CCT | CRI | Dimension (mm)
LxWxH
|
Mounting Type | ||
| VICTOR
24W/2400Lm/600 mm-LED SMD-S |
24 W | 2400 lm | ~100 lm/W | 4000 | 80 | 623 | 84 | 75 | Surface Mounted |
| VICTOR
48W/4800Lm /1200 mm-LED SMD-S |
48 W | 4800 lm | ~ 100 lm/W | 4000 | 80 | 1193 | 84 | 75 | Surface Mounted |
